TECHNICAL DATA
|
MICROPLAN – TA
|
MICROPLAN – TM
|
MICROPLAN – TR
|
MICROPLAN – TX
|
|
|
Electric motor
|
750 W / 220 V / 50 , 60 Hz
|
1100 W / 220 V / 50 , 60 Hz
|
1100 W / 220 V / 50 , 60 Hz
|
1500 W / 220 V / 50 , 60 Hz
|
|
|
Cutting Blade
|
8” (200 mm) Diamond Blade.
|
8” (200 mm) Diamond Blade.
|
8” (200 mm) Diamond Blade.
|
8” (200 mm) Diamond Blade.
|
|
|
Grinding Cup
|
150 mm Diamond Cup
|
150 mm Diamond Cup
|
150 mm Diamond Cup
|
150 / 200 mm Diamond Cup
|
|
|
Micrometer accuracy
|
7 Micron Stainless Steel / Brass
|
5 Micron Stainless Steel
|
5 Micron Stainless Steel
|
5 Micron Stainless Steel with stepmotor
|
|
|
Cutting unit accuracy
|
0.4 mm
|
0.2 mm
|
0.1 mm
|
0.1 mm
|
|
|
Cutting unit system
|
mechanical
|
Mechanical Rail / Liner Base
|
Mechanical Rail / Liner Base
|
Automatic
|
|
|
Thinning / Grinding system
|
manual
|
manual
|
Manual with stopper
|
Automatic / Digital Stepmotor controller
|
|
|
Control system
|
manual
|
manual
|
Manual / adjustable
|
Microprocessor control
|
|
|
Thin Section Holder
|
Auto holder with Vacuum pressure 1 + 1 Sample
|
Auto holder with Vacuum pressure 1 + 1 Sample
|
Auto holder with Vacuum pressure 1 + 3 Sample
|
Auto holder with Vacuum pressure 1 + 3 Sample
|
|
|
Vacuum Regulator Box/ Filter
|
Univac 2
|
Univac 2S
|
Univac 4
|
Autovac 4
|
|
|
Vacuum Pressure Pump
|
½ Hp , 750 mbar Vacuum Pump
|
¾ Hp , 800 mbar Vacuum Pump
|
¾ Hp , 850 mbar , 2 Stage Vacuum pump
|
1 Hp , Vacumet 900 , 2 Stage Vacuum pump
|
|
|
Circulator Cooling unit
|
30 Liters , Polymer tank , 60 W Circulating Pump
|
40 Liters , Polymer tank , 60 W Circulating Pump
|
40 Liters Stainless Steel Tank , 90 W Circulating Pump
|
40 Liters Stainless Steel Tank , 90 W Circulating Pump
|
|
|
Base / Frame
|
Cast Iron / Steel
|
Cast Iron / Stainless Steel
|
Cast Iron Oxidant Alloy / Stainless Steel
|
Cast Anti Oxidant Alloy / Stainless Steel
|
|
|
Approx. weight
|
50 Kg
|
60 Kg
|
70 Kg
|
95 Kg
|
|
|
Approx. dimensions ( Cm )
|
30 W × 60 L × 28 H
|
35 W × 70 L × 32 H
|
35 W × 75 L × 35 H
|
40 W × 95 L × 35 H
|
